Ammonia, a gas which has its roots in livestock farming, can have potentially detrimental effects on the lifetime and reliability of PV modules. Research into the degree of corrosive effects of this gas on modules is of utmost importance for any module manufacturer guaranteeing a certain specific lifetime for their product. Researchers from SCHOTT and SCHOTT Solar together with the DLG (Deutsche Landwirtschafts-Gesellschaft/German agricultural society) developed a test design involving humidity, temperature and ammonia gas. This design is based on permeation testing and microscopic analysis of samples aged under a controlled atmosphere or from outdoor exposure. Additionally, a highly accelerated test is presented which allows screening materials for use in PV modules within 84 hours. An Arrhenius type of model is used to calculate the acceleration factors involved. Based on this model, the proposed test design is equivalent to more than 20 years of outdoor exposure in the rural environment (in Central Europe).
The aim of this work is to study the effects of dark lines on the face of polycrystalline silicon solar cells. The formative processes of dark lines were observed by laser scanning microscopy. Following the initial appearance of a few etch pits on the surface of the cells, extending the etching time saw these etch pits increase in size, eventually merging to form a single line, known as a ‘dark line’. Dark lines are lines that are linked together by a series of contiguous dislocation outcrops and have the potential to reduce silicon wafer lifetime, adversely affect both the electroluminescence and the quantum efficiency of a solar cell, and have resulting negative effects on the cell’s electrical properties.
Savvy solar panel manufacturers understand that wringing excess costs from every stage of the value chain is simply the price of admission to today’s crowded market. They also know that reliability and quality are not only critical for delivering on a 25-year warranty promise, but also drive the true cost of energy over the lifetime of the system. This factor is becoming increasingly apparent, especially in industrial- and utility-scale solar projects, as they age and the power output of many lower quality systems begins to degrade to unexpected levels. Many of those systems used UL or IEC certifications as a proxy for good reliability. Unfortunately, UL certification is primarily concerned with user safety, and even the IEC requirements are not rigorous enough to ensure trouble-free operation throughout the system lifetime. High reliability and quality require testing and manufacturing methods that go far beyond the certification tests.
The eleventh edition of Photovoltaics International was published in February 2011 and features a special focus on PV modules from Fraunhofer CSP, SunPower and Heriot-Watt University. In addition, China Sunergy studies dark lines on mc-Si cells in Cell Processing and TU Freiburg looks at the challenges of the wire saw wafering process in Materials.
This paper focuses on the latest developments from research on MWT (metal wrap-through) solar cells at Fraunhofer ISE. An overview of the current cell results for mc-Si and Cz-Si material with both Al-BSF and passivated rear side is presented. Recent progress in cell technology and challenges to reaching efficiencies of 20% for industrially processed large-area MWT solar cells are also discussed. Up to recently, MWT cell efficiencies of up to 19% for Cz-Si and up to 17.5% for mc-Si have been reached with industrially feasible processing. Improvements to the design of the MWT cell to increase cell efficiency and to allow an easy module assembly are also presented in this paper, as are first calibrated IV measurements of MWT solar cells.
Solar enterprises will each be faced with the occasional surplus or lack of solar modules in their lifetimes. In these instances, it is useful to adjust these stock levels at short notice, thus creating a spot market. Spot markets serve the short-term trade of different products, where the seller is able to permanently or temporarily offset surplus, while buyers are able to access attractive offers on surplus stocks and supplement existing supply arrangements as a last resort.
As PV power generation adoption becomes more widely adopted globally, the grid-connected inverter market looks set to take its rightful role as a critically important element of solar installations. The grid-connected inverter market will deliver power quality and the stability of the electricity networks in order to ensure a stable and reliable grid operation. In order to keep up with these developments, network operators will release new grid codes to monitor the increased uptake, to which manufacturers must adhere. An additional obstacle for the inverter manufacturers is the wide range of requirements and norms that vary from country to country and, in many cases, even from utility to utility. This article presents a review of the new challenges facing grid-connected PV inverters in the light of these new developments.
One of the most important ways in which inorganic thin-film photovoltaics (TFPV) and organic photovoltaics (OPV) can distinguish themselves from more conventional crystalline silicon photovoltaics (c-Si PV) in the marketplace is through the commercialization of flexible photovoltaic products using those technologies. But flexible photovoltaics brings with it some challenges of its own in terms of excluding air and moisture from the cells; challenges that translate into opportunities for suppliers of advanced encapsulation materials and systems as well as for TFPV and OPV firms.
As yet, procedures for long-term tests of photovoltaic modules in outdoor conditions have not been considered by international standardization committees. Although many laboratories perform long-term PV outdoor tests, a commonly agreed and standardized procedure has so far not been adopted. The European Distributed Energy Resources Laboratories’ (DERlab) approach to filling the gap of international standardization has led to the development of a basic protocol that complies with European and international standards, while providing specific common guidelines and procedures for measuring the energy yield of PV modules for at least one year in outdoor conditions. The DERlab procedures for long-term PV module testing are described in this paper, and the range of analyses that can be derived from the data, such as module degradation, are discussed. The paper also presents the DERlab approach to measuring module performance in outdoor conditions, which can be used to complement energy-rating methods suggested in international standards. DERlab has created consistent measuring procedures that allow the direct comparison of the energy yield of solar modules taking into account the site-specific factors of different locations and varying climatic conditions, as well as a maintenance guideline.
This article provides an overview of the typical waste water treatment methods for crystalline silicon solar cell production. Firstly, a short description is provided of the main process steps of photovoltaic production and the types of waste water generated during these steps. Secondly, the typical waste water treatment methods of hydrogen fluoride (HF) precipitation and neutralization are presented. Furthermore, some options for the reuse of rinse water are discussed and several guidelines for the design of waste water treatment systems are given. Finally, the relative environmental impact of the waste water treatment compared to the emissions of the whole fab is presented using the life-cycle assessment (LCA) methodology.
